Features
- 22 Amp/Cabinet models developed by Multi-Layer IR technology for greater realism
- 79 Effects including modelling of renowned boutique pedals
- Up to 6 effects + 1 pedal effect can be used simultaneously
- Output EQ (Lo-Mid-Hi-Vol) for instant adjustment of overall sound quality
- 300 memory patches (250 factory presets + 50 users)
- Handy Guitar Lab app (iOS/Android) for editing on smartphones and access to new effects (requires connection via USB-C port)
- Looper function for recording phrases of up to 80 seconds
- 68 rhythm patterns that can be played back in sync with the looper
- AUX IN jack for connecting music players and other audio devices
- Auto-save and Revert functions for maximum flexibility when editing patches
- Tuner function that supports open and drop tuning
- 2-IN / 2-OUT Audio Interface function (via built-in USB-C port)
- Expression pedal for real-time control of Volume, Pitch and Wah (G2X FOUR only)
Specs
| MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS | 6 effects + 1 pedal effect | |
| USER PATCH MEMORIES | 300 | |
| USER PATCH MEMORIES | 44.1 kHz | |
| A/D CONVERSION | 24-bit 128× oversampling | |
| D/A CONVERSION | 24-bit 128× oversampling | |
| SIGNAL PROCESSING | 32-bit | |
| FREQUENCY RESPONSE | 20 Hz – 20 kHz (+0.5 dB/−0.5 dB) (10kΩ load) | |
| DISPLAY | 256×128 dot-matrix LCD | |
| INPUTS | INPUT | Standard mono phone jack |
| Rated input level: −20 dBu | ||
| Input impedance (line): 470 kΩ | ||
| AUX IN | Stereo mini jack | |
| Rated input level：–10 dBu | ||
| Input impedance (line)：10 kΩ | ||
| OUTPUTS | LEFT/RIGHT | Standard mono phone jack |
| Maximum output level: +9.3 dBu (when output impedance 10 kΩ or higher) | ||
| PHONES | Stereo mini jack | |
| Maximum output power: 20 mW + 20 mW (into 32Ω load) | ||
| INPUT S/N | 122 dB | |
| NOISE FLOOR (RESIDUAL NOISE) | LEFT/RIGHT | –99.3 dBu |
| PHONES: | –99.3 dBu | |
| CONTROL INPUT | FP02M input (G2 FOUR only) | |
| POWER | AC adapter | 9V DC 500mA center negative (ZOOM AD-16) |
| • USB bus power is supported. | ||
| USB | USB 2.0 Type-C port (use cable that supports Type-C) | |
| Handy Guitar Lab: USB 1.1 Full Speed | ||
| Audio interface: USB 2.0 Full Speed, | ||
| 44.1kHz, 32-bit, 2-in/2-out | ||
| • Use a USB cable that supports data transfer. | ||
| DIMENSIONS | G2 FOUR | 145 mm (D) × 184 mm (W) × 71 mm (H) |
| G2X FOUR | 150 mm (D) × 274 mm (W) × 71 mm (H) | |
| G2 FOUR | 707 g | |
| G2X FOUR | 951g |
